Corinex AV200 - Adapter Status Details; PHY Status; Multicast Status; VLAN Status

Adapter Configuration
Corinex AV200 Powerline Ethernet Wall Mount F
14
PHY Status
Notches Indicates whether or not frequency
notches are enabled. notches should
always be enabled, in order to eliminate
interference with Radio Amateur bands
specified by the local authorities.
Power Control Indicates status of the power control
mechanism (described in chapter
3.4.4).
Multicast Status
IGMP Aware Multicast Syndication Shows the status of the IGMP settings
(described in chapter 3.4.5).
Multicast Bindings Shows all multicast bindings between
multicast IP Addresses and AV200
Powerline MAC addresses.
VLAN Status
VLAN Configuration Indicates whether or not VLAN (virtual
networking) is enabled.
VLAN Tag Shows the selected VLAN Tag. All traffic
from the ethernet port carries this tag.
VLAN Priority Shows the selected priority, which is
inserted into the VLAN tag.
