IntelliCarb Drop-In Ice Cooled Installation Guide
© 2003-2017, Cornelius Inc. - 19 - Publication Number: 630460204INS
Preparing for Operation
On units Without Electrically Operated Valves, Skip Steps 1 and 2 Below
1. Plug transformer into electrical outlet. The 24V supply must be connected in the dispensing tower.
2. Turn the key-switch to the ON position. The ice-bin lid must be closed to allow the valves to operate.
3. Adjust the CO
2
regulators as indicated in the following chart:
4. Operate each valve until product is flowing.
5. Fill the bin with 32F ice. DO NOT use ice taken directly from the freezer.
6. Adjust the brix (water-to-syrup ratio) for post-mix valves.
Post-Mix
Regulator Pressure Setting
Primary (Carbonator) feed line to Carb secondary regulator 90-120 PSI
Secondary, Sugared Syrup Tank 55 PSI min.
Secondary, Diet Syrup Tank 8-12 PSI
Secondary, B-I-B 60 PSI min
