Cornelius IDC 215 - Flow Diagram - Eight Valve Unit with Eight Line Cold Plate

IDC 2XX Service Manual
Publication Number: 621057403SER - 4 - © 2007-2019, Cornelius Inc.
FLOW DIAGRAM - EIGHT VALVE UNIT WITH EIGHT LINE COLD PLATE
THIS EQUIPMENT MUST BE INSTALLED WITH ADEQUATE BACKFLOW PROTECTION
TO COMPLY WITH APPLICABLE FEDERAL, STATE AND LOCAL CODES.
S8
S7
S6
S5
S4
S3
S2
S1
CO2 SOURCE 100-110 PSIG
SECONDARY REGULATOR
CO2
CYLINDER
SYRUP BIB'S 60 PSIG
PUMP & MOTOR ASY
PRESSURE
REGULATOR
OR BOOSTER
PUMP MAY BE
REQUIRED
CITY WATER
FIXED REGULATOR
ICE
CHUTE
COLDPLATE
CW
PW
CW
PW
CARB TANK OUT
CARB TANK IN
CARB WTR IN
PLAIN WTR IN
IN
OUT
CARB TANK
2
4
W3
W2
W2W1
7
6
W3
W2
W3
W1
4
3
2
1
8
7
6
5
PW = PLAIN WATER
CW = CARBONATED WATER
VALVES
2
34
5
6
7
TOTAL
FLEX
MANIFOLD
TOTAL
FLEX
MANIFOLD
CW
PW
CW
PW
8
INCLUDED WITH UNIT
8
1
3
5
1
WATER
FILTER
figure 1.
