IDC 2XX Service Manual
© 2007-2019, Cornelius Inc. - 3 - Publication Number: 621057403SER
INTRODUCTION
DESCRIPTION
The IDC series of ice dispensers solves your ice and beverage service needs in a sanitary, space saving,
economical way. Designed to be automatically filled with ice from a top mounted ice machine or manually filled with
ice from any remote ice-making source, these dispensers will dispense cubes (up to 1-1/4 inch in size), cubelets,
and compressed or extruded style ice. In addition, the units include beverage faucets, a cold plate, an internal
carbonator tank and an external pump for the carbonator, and are designed to be supplied direct from syrup tanks
with no additional cooling required.
THEORY OF OPERATION
The rate of CO
2
solubility increases with cold water. IDC System provides pre–chilled cold water from the cold plate
and mix with CO
2
in the carbonator tank. The water is introduced into the tank with a high volume 125gph Procon
pump and high torque motor.
The amount of carbonated water reserve is controlled by a probe mounted in the tank. The probe is called a “liquid
le
vel probe”. The liquid level probe senses the water level in the tank. Probe controls the pump “ON” and “OFF”
cycle through the “liquid level board” located on the main control board.
NOTE: The probe works on a 5 mVDC current that continually reverses direction to prevent probe
co
rrosion.
SPECIFICATION
Model Descriptions: IDC 215
B=Beverage
C=Coldplate
H=Internal Carb
Z=No Drip Tray
IDC 255
B=Beverage
C=Coldplate
H=Internal Carb
Z=No Drip Tray
Ice Storage: 215 Pounds 255 Pounds
Maximum Number of Faucets
Availa
ble:
10 10
Built–in Cold Plate: Yes Yes
Electrical: 120/1/60,
9.3 A
mps of Total Unit Draw
220/1/50,
4.7 Amps of Total Unit Draw
Dimensions:
Width
Depth
Height
30 inch
30-11/16 inch
36 inch (to top of bin)
36-3/4 inch (to top of lid)
30 inch
30-11/16 inch
39 inch (to top of bin)
39-3/4 inch (to top of lid)
CO
2
Operating Pressure 75-psig (max) 75-psig (max)
