Cornelius SPIRE 4.2 - Installation Instructions; Kit Part List and Tools Required; Initial Shutdown and Power Disconnection

Manual Installation Conversion Kit 4.1 To 4.2
©2019, Cornelius Inc. - 3 - Publication Number: 629097805INS
MANUAL INSTALLATION CONVERSION KIT SPIRE 4.1 TO 4.2
INSTALL KIT PART LIST:
TOOLS REQUIRED:
INSTALLATION INSTRUCTION:
1. Shut Down unit per proper shutdown procedure
2. Unplug unit from its AC Power source.
PART NUMBER DESCRIPTION QTY
620070411 Ebox cover (pre-assembled with all required labels and
new wiring diagram)
1
620070273 Door service cover pre-assembled w/ mounting screws
and labels)
1
N/A AIO Display assembly (pre-assembled with bezel and
mounting bracket and screws)
1
N/A LX3 mounting bracket assembly (pre-assembled w/LX3,
terminal block, display on/ off switch and required wiring/
jumpers)
1
62058545-002 Breaker Circuit 5A
1
620058733-003 Ferrite Snap- On 240 Ohm
1
620058733-007 Ferrite Snap- On 225 Ohm
1
620070445 Flex Antenna Kit
2
620070523-200 MFV Board Assy
1
620070550 Bracket 3rd Circuit Breaker
1
620070556 Cable Clamp
2
629097805 Installation Instructions
1
Description
#2 Phillips Screwdriver
Utility Knife or side-cutting pliers
Flat Head Screwdriver
11/32” nut driver or equivalent
!
WARNING
Only trained and certified electrical, plumbing and refrigeration technicians should
service this unit.
All wiring and plumbing must conform to National and Local Codes. Failure to
comply could result in serious injury, death or equipment damage.
