Disassembling and refitting
Coway co., Ltd
3-3
No. Part name Description Reference picture
1 Cover-top 3) Detach the 6 clips for the cap-main
tank ASSY.
4) Remove the anti-bacterial filter
ASSY in the direction of the arrow.
5) Remove the separator ASSY in the
direction of the arrow.
