Coway CHP-671R/L User Manual

Parts location diagrams
Coway co., Ltd
6-3
6-3 PBA location diagram
6-3-1 MAIN PBA
1 CN16
SMPS
Pin No. Signal
1 GS
2 + 5 V
3 GS
4 GS
5 + 24 V
6 + 24 V
2 CN19
AC IN
Pin No. Signal
1
Voltage rating that
matches it on the
rating plate.
2
3 CN15
COMP.
#1 @
2 5 6 73 4
!
9 8 0
