Coway CHP-671R/L User Manual

Parts location diagrams
6-4
Coway co., Ltd
4 CN13
HEATER
Pin No. Signal
1
Voltage rating that
matches it on the
rating plate.
2
7 CN12
LEVEL SENSOR (LOW)
Pin No. Signal
1 GS
2 + 5 V
3 SIGNAL
0 CN6
LEVEL SENSOR (OVER)
Pin No. Signal
1 GS
2 + 5 V
3 SIGNAL
5 CN17
BOOST PUMP (Option)
Pin No. Signal
1 GS
2 + 24 V
8 CN10
LEVEL SENSOR (MIDDLE)
Pin No. Signal
1 GS
2 + 5 V
3 SIGNAL
! CN4
COOL SENSOR
Pin No. Signal
1 SIGNAL
2 GS
6 CN18
NOS/FEED
Pin No. Signal
1 GS
2 + 24 V
3 + 24 V
4 GS
9 CN7
LEVEL SENSOR (HIGH)
Pin No. Signal
1 GS
2 + 5 V
3 SIGNAL
@ CN1
COOL SENSOR
Pin No. Signal
1 + 5 V
2 -
3 SIGNAL
