Disassembling and refitting
3-4
Coway co., Ltd
3-1-3 Cover-front lower ASSY separation
No. Part name Description Reference picture
1 Cover-front
lower ASSY
1) Push the drain hose with your
hand to open.
2) Remove the 1 screw from the
cover-front lower ASSY.
: M 4X10
3) Remove the cover-front lower
ASSY in the direction of the arrow.
