Coway CHP-671R/L - Page 21

Disassembling and refitting
Coway co., Ltd
3-5
No. Part name Description Reference picture
2 Filter 1) Use a
‘ - ’ screwdriver to remove
fittings connected to the filter.
2) Remove the filter in the direction of
the arrow.
3 Tray 1) Remove the tray in the direction of
the arrow.
2) Remove the grill-tray in the
direction of the arrow.
