Coway CHP-671R/L - Cover-Rear ASSY Separation

Disassembling and refitting
3-14
Coway co., Ltd
3-1-6 Cover-rear ASSY separation
No. Part name Description Reference picture
1 Cover-rear 1) Remove the 6 screws from the
cover-rear.
: 4-THT 4X10 (
◯)
: 2-PHT 6X18 (
◯)
2 Power cord 1) Remove the 1 screw from the
power cord.
: PHT 3X8 (washer)
2) Remove the power cord in the
direction of the arrow.
