Disassembling and refitting
Coway co., Ltd
3-13
No. Part name Description Reference picture
8 Valve-feed/
NOS ASSY
1) Use a
‘
-
’
screwdriver to remove
fittings connected to the valve-
feed/NOS ASSY.
2) Remove the 1 screw from the
valve-feed/NOS ASSY.
: THT 4X12
9 Bracket-filter 1) Remove the 2 screws from the
bracket-filter.
: 2-THT 4X10
