Disassembling and refitting
Coway co., Ltd
3-7
No. Part name Description Reference picture
2 PBA-front
ASSY
1) Remove the 2 screws from the
cover-front PBA.
: 2-THT 4X12
2) Remove the PBA-front ASSY in
the direction of the arrow.
3 Deco-
multifaucet
ASSY
1) Push the deco-multifaucet ASSY
hook to detach.
