Disassembling and refitting
Coway co., Ltd
3-9
No. Part name Description Reference picture
1 PBA ASSY 5) Remove the 2 screws from the
PBA-SMPS.
: 2-THT 4X10
2 Sensor-
capacitance
water level
1) Use a
‘ - ’ screwdriver to remove the
fittings.
2) Use a ‘ - ’ screwdriver to remove
the sensor-capacitance water level
clip.
3) Remove the sensor-capacitance
water level in the direction of the
arrow.
