Disassembling and refitting
Coway co., Ltd
3-11
No. Part name Description Reference picture
4 Faucet-hot
water ASSY
1) Remove the 2 screws from the
faucet-hot water ASSY.
: 2-THT 4X12
2) Remove the faucet-hot water
ASSY in the direction of the arrow.
5 Bracket-
faucet
1) Remove the 2 screws from the
bracket-faucet.
: 2-THT 4X10
