Coway P-07QR Service Manual

Disassembling and refitting
4-4
Coway co., Ltd
4-2-3 Front Assy Part separation
No. Part name Explanation Reference picture
1 Front Assy 1) Remove the 2 screws on the top
of the Front Assy.
: 2-M4x10
2) Separate the Front Assy
by
pulling it in the direction of the
arrow.
2 Filter 1) Remove the fittings connected to
each Filter.
2) Remove Filters.
3 Water valve 1) Separate the Water valve from
the membrane filter.
(P-07QR/L only)
