CP Electronics UNLCDHS - User

30
UNLCDHS Programming – User
Basic Parameters for all models including ‘-PRM’, ‘-PRM-2CH’, ‘-DD/SR’ and ‘-AD’ and their variants
Parameter Default Range / Option Description
Select Scene 1 1 – 8 The preset dimming levels are as follows (does not operate the relay outputs):
Scene 1 – Maintained illuminance
Scene 2 – 100%
Scene 3 – 75%
Scene 4 – 50%
Scene 5 – 25%
Scene 6 – 15%
Scene 7 – 10%
Scene 8 – 0% (min)
Select Scene
(pre V3 models)
6 1 – 6 The preset dimming levels are as follows:
Scene 1 – 0% (minimum)
Scene 2 – 10%
Scene 3 – 25%
Scene 4 – 50%
Scene 5 – 75%
Scene 6 – 100%
Scene Up – – Changes the scene from 1 up to 8. (1–6 for pre V3 models)
Scene Down – – Changes the scene from 8 down to 1. (6 down to 1 for pre V3 models)
Set Scene Level
(V3)
0 0 – 255 Changes a particular scene’s preset level. Select the scene rst using Select Scene
and then send Set Scene Level.
255 = 100%
191 = 75%
128 = 50%
64 = 25%
26 = 10%
0 = 0% (min)
Raise – – Increases light level. Reverts to programmed light levels when absence detected.
Lower – – Decreases light level. Reverts to programmed light levels when absence detected.
Manual Override
On
– – Turns lights on and reverts to automatic operation aer the period set by Manual
Timeout in the Detector Params menu.
Manual Override
O
– – Turns lights o and reverts to automatic operation aer the period set by Manual
Timeout in the Detector Params menu.
Manual Override
Cancel
– – Cancels the manual on and o overrides, returning the detector to normal
operation.
Note: Certain parameter functions are only available in specic versions of the detectors and these are indicated under the aected parameter headings
within the brackets e.g. LUX Learn Level (V3).
