2.1.0 INTRODUCTION
This chapter contains instructions for unpacking and installing the CMP 200® and CMP 200® DR X-ray
generators. This chapter also describes the basic wiring and setup of the generator (console, X-ray tube,
AC mains, etc), allowing for initial power-up of the generator. This is followed by tube seasoning and auto
calibration.
2.2.0 UNPACKING
1. Inspect the pack for evidence of shipping damage. If there is evidence of shipping damage, note
this in the event that a damage claim is justified. Taking pictures of the damage is also
recommended.
2. Remove the cardboard outer pack. See the cautionary note below before removing the pack.
CAUTION
: OPEN THE CARDBOARD PACK CAREFULLY. SHARP TOOLS MAY DAMAGE THE
CONTENTS.
3. Set aside the cardboard pack(s).
WARNING
: THE GENERATOR MAIN CABINET (WITH HT OIL TANK) WEIGHS APPROXIMATELY
135 POUNDS (61 KG).
ONE PERSON SHOULD NOT ATTEMPT TO LIFT OR MOVE THIS ASSEMBLY
WITHOUT PROPER EQUIPMENT OR ASSISTANCE.
4. Carefully lift the generator from the pallet.
5. Inspect for evidence of shipping damage, including loose hardware.
6. Remove and unpack the control console, if included. The optional touchscreen console is shipped
with the base as a separate component. Remove and unpack the base and check for any
damage.
7. Remove and unpack the optional hand switch and the optional mini-console control unit, if
included.
8. Unpack the manuals and any other paperwork that may be packed with the generator.
9. Keep the shipping containers. In case of shipping damage, place the unit back in its shipping
pack(s) and notify the carrier and the customer support department as described in chapter 1 of
this manual.
2.3.0 REMOVING THE GENERATOR COVER
1. Remove and set aside the screws and washers securing the cover to the generator chassis.
2. Carefully lift the cover off the chassis.
