CPI CMP 200 Series - 10.2

CPI Canada Inc. Interfacing and Programming 3C
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200  X-Ray Generator Service Manual Ch # 901476-04 Rev. C Page 3C-73
3C.10.2 DAP SETUP Menu Items (Cont)
FUNCTION
(MEMBRANE
CONSOLE)
FUNCTION
(GenWare)
DESCRIPTION
DAP
MEMBRANE CONSOLE ONLY:
Allows access to a submenu used to reset the DAP display, test the DAP device,
and print a test label. This selection is available in the DAP SETUP menu when the DAP function is ON.
PRINT This function is
not available in
GenWare
Prints a DAP label. The printer will print the date and time near the top of the label, and the
accumulated Dose-Area Product (mGycm
2
) near the middle of the label. This information is
retrieved from the generator at the time the label is printed. Several headings are also printed
on the labels; the corresponding patient information must be manually entered.
RESET Reset
Resets the DAP display to zero.
TEST Test
Tests the DAP circuits by counting the number of test pulses (refer to TEST VALUE 1, above).
A pass / fail message will be presented after the DAP test, and the actual number of test pulses
counted will be displayed.
