2.6.3 Stator Connections (Cont)
FUNCTION CONNECT TO
SHIFT J7-6.
MAIN J7-5.
COMMON J7-4.
GROUND J7-3.
THERMAL SWITCH (Term 1) J7-2.
THERMAL SWITCH (Term 2) J7-1.
Dual-speed Starter
Refer to figure 2-6 for the X-ray tube stator connections for the dual-speed starter.
TUBE 1
CMP 200
_
DSS.CDR
CMS
TUBE 1
Figure 2-6: Stator connections on dual-speed starter chassis
1. Route the X-ray tube stator cable to the stator terminal block on the back of the dual-speed
starter chassis. Refer to figure 2-6.
THE STATOR CABLE FOR THE DUAL SPEED STARTER MUST BE SHIELDED. THE SHIELD
FOR THE STATOR CABLE MUST BE PROPERLY GROUNDED AT BOTH THE TUBE END
AND THE GENERATOR END OF THE CABLE. CONNECT THE GENERATOR END OF THE
SHIELD TO THE GROUND TERMINAL ON THE STATOR TERMINAL BLOCK (FIGURE 2-6).
