Out of Service Line Indication
The Talos Bill Acceptor provides, as part of the interface connector, an out of service
indicator signal. The out of service signal will be active when the bill acceptor is not enabled
to accept bills for any reason. Such conditions include: full bill magazine, missing bill
magazine, all denominations disabled, jams, and internal malfunctions. The output, when
active, sources 10ma at 5 Volts DC.
An out-of-service output signal is available under all interfaces. The NISR, MDB, and EBDS
interfaces also provide serial messages to indicate various out-of-service conditions.
Isolated Low Level Pulse (ILLP) Interface
The ILLP interface is an isolated interface that sends credit information in the form of pulses
via the Credit Relay. From one to four pulses (model dependent) per unit of credit is
selectable along with two different pulse patterns (model dependent). Optically isolated sink
or source inputs provide external acceptance enable control for three different bill types.
Escrow return of the last bill is also supported via an optically isolated sink or source
ESCROW input.
Connections
Pin Name (all pins refer to P1)
Type
115 VAC
pin
24 VAC
pin
12VDC pin
115VAC HOT / 24VAC HOT/ 12VDC HOT
Power
20
3
19
115VAC NEUTRAL / 24VAC NEUTRAL/
12VDC Return
Power 4 2 16
Earth
Power
21
None
None
Denom 1 ENABLE, High
Input
15
15
15
Denom 2 ENABLE, High
Input
14
14
14
Denom 3 ENABLE, High
Input
13
13
13
ESCROW, High
Input
12
12
12
Denom 1 ENABLE, Low
Input
27
27
27
Denom 2 ENABLE, Low
Input
28
28
28
Denom 3 ENABLE, Low
Input
29
29
29
ESCROW, Low
Input
30
30
30
