Talos Operation and Service Guide
24
Send
In response to an INTERRUPT signal, the control system will supply a SEND signal to cause
the serial transfer of the data message from the validator. A control system request for
retransmission of the data message will be initiated as per the timing diagram of Figure 10.2.
Serial/Pulse
This line must be disconnected to use the NISR interface.
To Next Page
