CPI TALOS - NIP Input Signals; Accept Enable

Talos Operation and Service Guide
26
Connections
Pin Name (all pins refer to P1)
Type
115 VAC
pin
24 VAC
pin
12 VDC
pin
115VAC HOT / 24VAC HOT/ 12VDC HOT
Power
20
3
19
115VAC NEUTRAL / 24VAC NEUTRAL/
12VDC Return
Power
4
20
16
Earth
Power
21
None
None
LOW LEVEL GROUND
Ground
10
10
10
SERIAL / PULSE_NOT (must be tied low)
Input
9
9
9
ACCEPT-ENABLE_NOT
Input
24
24
24
CREDIT-PULSE_NOT
Output
7
7
7
CREDIT RELAY, Normally Open
Output
16
2
2
CREDIT RELAY, Common
Output
1
1
1
OUT-OF-SERVICE POWER
(200 ohms to +5VDC)
Output
25
25
25
OUT-OF-SERVICE_NOT
Output
22
22
22
