Step 3
Tighten the 8 at head socket head screws to a snug-t using a criss-
cross method.
It is recommended to do one full turn of the Allen wrench only before
moving to the next screw until snug.
After all screws are snug, use the criss-cross method and tighten all
screws to 6 foot pounds of torque pressure (72 inch pounds).
The screws should protrude the retainer slightly when proper torque
pressure has been reached.
***See picture below for example.
Note: The screw in the forefront is properly torqued
while the screw to the left and right are over and under tightened
respectively.
FLEX HEAD ASSEMBLY INSTRUCTIONS
24/7 Technical Support- Toll Free 1-877-472-8200
32
Concrete Polishing Solutions- G-250XTP Operator’s Manual
