Step 6 Con’t
Using a criss-cross method torque all nuts to 6 foot pounds.
Final torque of lock
nuts.
Final assembly as viewed from
the main mounting plate side
showing proper alignment of
holes.
FLEX HEAD ASSEMBLY INSTRUCTIONS
24/7 Technical Support- Toll Free 1-877-472-8200
37
Concrete Polishing Solutions- G-250XTP Operator’s Manual
