DSCP (DiffServ): Differentiated Services Code Point is the successor to TOS (Type of Service). Use this field to select traffic based on
the DSCP header in each IP packet. This field is sometimes set by latency sensitive equipment such as VoIP phones. If you know
specific DSCP values, you can input one here.
DSCP Negate: When checked this rule will match on any packet that
does NOT match the DSCP field.
Protocol: Select from the dropdown list to specify the protocol for a
particular data use. Otherwise, leave “Any” selected.
• Any
• ICMP
• TCP
• UDP
• GRE
• ESP
• SCTP
Source IP Address, Source Netmask, Destination IP Address, and
Destination Netmask: Specify an IP address or range of IP
addresses by combining an IP address with a netmask for either
“source” or “destination” (or both). Source vs. destination is defined
by traffic flow. Leave these blank to include all IP addresses (such as
if your rule is defined by a particular port instead).
EXAMPLE: If you want to associate this rule with your guest LAN, you could input the IP address and netmask for the guest LAN here (leaving the
last slot “0” to allow for any user attached to the guest network):
• Source IP Address: 192.168.10.0
• Source Netmask: 255.255.255.0
Failover: (Default: Selected.) When this is selected and traffic from the chosen WAN device for this rule is interrupted, the router will fail
over to another available WAN device. Deselect this option to restrict this traffic to only the selected WAN interface.
