CraftBot Flow - CraftBot Flow and Flow XL Printer Components

USER MANUAL V1.0
WWW.CRAFTBOT.COM
1. Filament guide tube
2. Touchscreen LCD display
3. Hotend
4. Build plate
5. Z axis rod
6. USB connector for flash drive
7. Extruder
8. Filament guide tube holder
9. Filament spool holder
10. Filament spool
11. ON / OFF switch
12. AC power cable
13. LAN connection
14. Reset button
1.1. CraftBot Flow / Flow XL printer components
The model displayed is the CraftBot Flow printer. The difference between the two models is the frame height.
See Specifications for the different dimensions.
2
4
1
3
5
6
7
8
14
13
12
11
9
10
