USER GUIDE
6
1. Touchschreen LCD display
2. Filament guide tube
3. Nozzle
4. Removable glass build plate
5. Leveling knobs
6. Z axis rod
7. Filament spool holder
8. Filament spool
9. Filament guide tube holder
10. Extruder
11. USB-A for flash drive
12. USB-B socket
13. AC power socket and ON/OFF switch
2. INTRODUCING THE CRAFTBOT 3D PRINTER
3
1
2
4
6
5
7
8
9
13
12
10
11
