11
VISE
The vise has a quick tighten/release lever
and depending on the cut angle or work-
piece shape, you can remove or install
the aluminum vise clamp plate.
TO USE THE VISE:
Raise the band saw and lock it in position
by closing the ON/OFF valve. See figure-
8.
Figure-8 ON/OFF valve
Position the work-piece between the jaws.
Close the jaws so that they are 1/8" from
the work-piece by using the hand wheel.
Figure-9 Vise
Use the vise lock lever to secure the
work-piece and release the jaws to move
the work-piece after the cut.
BLADE SELECTION
The CX117 uses a 1" wide x 97.5" long x
0.03" thick band saw blade.
Selecting the right blade depends on a
variety of factors, such as the type of
material being cut, hardness of material,
material shape and machine capability.
Always do some research to get the right
blade to match your needs.
USING BLADE GUIDES
To ensure straight cuts the upper blade
guides should be as close as possible to
the work-piece.
TO ADJUST THE UPPER BLADE
GUIDES:
Loosen the lock knob shown in figure-10
and slide the upper blade guide assembly
as close to the work-piece as possible,
then tighten the lock knob.
Figure-10 Blade guide assembly with lock
knob
