CX418 DUST COLLECTOR
Assembly Instructions, Continued
Installing the Collector Bag Housing
Select the 2 Collectors, 2 Gaskets
and 16 Nuts, Bolts and Washers from
the Parts Package.
Place one Gasket and a Collector on
the Collector Body outlet as illustrated
and tighten securely.
Repeat the above with the second
Collector.
This figure illustrates how the
assembly of the CX418 Dust
Collector should appear at this point.
.
