CX418 DUST COLLECTOR
Assembly Instructions, Continued
Installing the Triple Gate Assembly
Select the Triple Gate unit and a self-
tapping screw. Mount the Gate on the
flange of the Impeller with the two
screw holes aligned. Use the self-
tapping screw to secure the unit.
The Completed Craftex CX418
Dust Collector
Your Dust Collector is now ready to
be put into service. Before connecting
to a power source be sure that the
power source is correctly grounded
and of the correct voltage and
amperage.
