CX418 DUST COLLECTOR
Assembly Instructions, Continued
Collector Assembly
Select the Rubber Gasket and the 8
Gasket Screws and Washers from the
Parts Package. Place the Rubber
Gasket on the flange opening of the
Motor/Impeller Assembly as shown.
Select the Collector Body and
carefully mount it on top of the flange
opening being cautious so as to
prevent damage to the Gasket.
Using the 8 Gasket Screws, Nuts and
Washers, securely fasten the
Collector Body to the Motor/Impeller
Assembly.
Rubber Gasket
