CX418 DUST COLLECTOR
Assembly Instructions, Continued
Assembling the Collector
Supports
Select the 2 Collector Supports and
assemble the lower flange to the
Base Assembly using the appropriate
nuts, bolts and washers as indicated.
Connect top of the Collector Supports
to the Collector Frames using the
appropriate nuts, bolts and washers
as illustrated.
