Craftsman CMPPN23 User Manual

5
ENGLISH
TOOL SPECIFICATIONS
Height (inch/meter) 6.3/0.16
Width (inch/meter) 1.7/0.04
Length (inch/meter) 8.9/0.22
Weight (lbs/kg) 2/0.91
Recommended Operating Pressure 60‑100 psi (4.1 to 6.9 bar)
Air Consumption per 100 cycles 1.56 SCF
Loading capacity 170 nails
Lubrication Oil
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove air supply before
making any adjustments or removing/installing
attachments or accessories. An accidental actuation
can causeinjury.
The label on your tool may include the following symbols. The
symbols and their definitions are asfollows:
BPM .................... beats per minute
V ......................... volts
min ..................... minutes
j
or DC ............direct current
…/min ..............per minute
RPM .................... revolutions per
minute
A ......................... amperes
Hz .......................hertz
W ........................watts
Wh ......................watt hours
n
o
.......................no load speed
n .........................rated speed
c
.....................safety alert symbol
h
..................... wear respiratory
protection
f
..................... wear eye protection
i
..................... Class II Construction
(double insulated)
g
..................... wear hearing
protection
a
..................... read all
documentation
n
..................... avoid staring at
light
l
or AC............alternating current
Ah ....................... amp hours
mouth, eyes, or lay on the skin may promote absorption of
harmfulchemicals. Direct particles away from face andbody.
• Use the appropriate dust extractor vacuum to remove
the vast majority of static and airborne dust. Failure
to remove static and airborne dust could contaminate the
working environment or pose an increased health risk to
the operator and those in closeproximity.
• Use clamps or other practical ways to secure and
support the workpiece to a stable platform. Holding
the work by hand or against your body is unstable and may
lead to loss ofcontrol andinjury.
• Air vents often cover moving parts and should be
avoided. Loose clothes, jewelry or long hair can be caught
in movingparts.
Additional Safety Information

WARNING: Never modify the power tool or any part of
it. Damage or personal injury couldresult.

WARNING: ALWAYS use safety glasses. Everyday
eyeglasses are NOT safety glasses. Also use face or
dust mask if cutting operation is dusty. ALWAYS WEAR
CERTIFIED SAFETYEQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratoryprotection.

WARNING: Some dust created by power sanding,
sawing, grinding, drilling, and other construction activities
contains chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm.
Some examples of these chemicalsare:
• lead from lead‑based paints,
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from
chemically‑treatedlumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter
out microscopicparticles.
• Wear protective clothing and wash exposed areas
with soap and water. Allowing dust to get into your

WARNING: This tool is not intended for use in
potentially explosive atmospheres and is not insulated
from coming into contact with electricalpower.
• Use the pneumatic tool only for the purpose for which it
wasdesigned.
• Do not use the tool as ahammer.
• Always carry the tool by the handle with hand off
both triggers.
• Never lift, pull, lower, or carry the tool by the airhose.
• Whipping hoses can cause severe injury. Always check for
damaged or loose hoses orfittings.
• Never direct compressed air at yourself or anyoneelse.
• Compressed air can cause severeinjury.
• Do not alter or modify this tool from the original design or
function without approval fromCRAFTSMAN.
• Never clamp or tape the trigger in an actuatedposition.
• Ensure tool is always safely engaged on the workpiece and
cannotslip.
• Never leave a tool unattended with the air hoseattached.
TO PREVENT ACCIDENTAL INJURIES:
• Never place a hand or any other part of the body in fastener
discharge area of tool while the air supply isconnected.
• Never actuate the tool unless nose is directed at thework.
• Do not actuate the tool whileloading.
• Keep hands and body parts away from the discharge
area of the tool. While in use NEVER grasp the tool by the
magazine or canister, a mis‑driven fastener can exit the
nose causinginjury.
