20
31 5 125502 ≈ ■‡◘ ⌂ Paint, Epoxy, Part “A”, Blue
32 5 125503 ≈ ■‡◘ ⌂ Paint, Epoxy, Part “B”, VF-525
33 1 2-31003-234 + § O-Ring, 2-234, Buna-N, 70 Duro Buna-N
34 1 127270 ≈ Plug, Cap, 3.37”, Tapered PE
35 1 127267 − Resistor, Moisture, Sensor
36 2 125856 − Sensor, Moisture, ¼-18NPT, AMP PP / SS
37 1 127249 § Wire, Jumper, Green, 6”, Bar/O-Ring, 8G
38 1 039462 ≈ Tie, Cable
39 2 125855 ♦ § Screw, SHCS, M5 x 0.8 x 8 Stainless Steel
40 2 134013 − Connector, Wire, Clip
49 1 See Table ∑⌂ Striker Plate
50 * See Table ∆∑⌂ Shims
51 8 143110 ∑⌂∩ Screw, SHCS, M10 x 1.5 x 35
8 131147 ∑⌂∩ Screw, SHCS, M10 x 1.5 x 35 (DG Model ONLY)
52 1 See Table ∑⌂∩▲O-Ring, Buna-N, 70 Duro Buna-N
*NOTE: Quantity dependent on Blade clearance, nominal is 0.09 Shim Stack, with 0.003 gap between Blade and Plate.
SC 18 Frame - PARTS LIST
ITEM QTY PART NO. DESCRIPTION MATERIAL
