26
NOTE:
Kits contain hardware your pump may not require.
Bearing Kit includes:
• Bearing Retaining Snap Ring
• Large Ball Bearing
• Small Ball Bearing
• Wavy Spring Washer
Volute Kit includes:
• Wear Ring (pressed)
• Volute (painted)
Bearing Bracket Kit includes:
• Bearing Bracket (painted)
Seal Plate Kit includes:
• Large Pipe Plug
• Seal Plate (painted)
Terminal Block Kit includes:
• Terminal Block
• Internal Retaining Ring
• Terminal Block O-Ring
• Green Wire Jumper
• Terminal Block Screw
Hardware Kit includes:
• Socket Head Cap Screws (for Housing)
• Impeller Bolt and Washer Set
• Socket Set Screw
• Socket Head Cap Screw (for Sensor)
Moisture Sensor Kit includes:
• 18” Orange Wire Jumper
• 24” Blue Wire Jumper
• Moisture Sensor Resistor
• Moisture Sensor
• 36” Orange Wire Jumper
• Wire Connector Clip
• 24” Orange Wire Jumper
Seal Kit includes:
• Lower Volute O-Ring (option 1)
• Lower Volute O-Ring (option 2)
• Lower Volute O-Ring (option 3)
• Seal Plate upper O-ring and Stator Lower O-ring
• Terminal Block O-ring
• External Retaining Ring
• Key
• Upper Mechanical Seal
• Lower Mechanical Seal
NOTE: Kit contains hardware your pump may not require.
Seal Kits
Seal Kit
Part No.
I.B. Seal
Part No.
I.B. Seal
Material
O.B. Seal
Part No.
O.B Seal
Material
138618 133029 Carbon / Ceramic 133029 Carbon / Ceramic
138580 (STD) 133029 Carbon / Ceramic 133029SD Silicon Carbide / Silicon Carbide
138619 133029 Carbon / Ceramic 133029SB Tungsten Carbide / Tungsten Carbide
138620 133029SD Silicon Carbide / Silicon Carbide 133029SD Silicon Carbide / Silicon Carbide
138621 133029SD Silicon Carbide / Silicon Carbide 133029SB Tungsten Carbide / Tungsten Carbide
138622 133029SB Tungsten Carbide / Tungsten Carbide 133029SB Tungsten Carbide / Tungsten Carbide
