Crane BARNES SITHE 3SCM - Page 28

28
1750 RPM
Model No.
Rotor Kit
Part No.
Stator / Motor Housing
Kit Part No.
─ SC ─ ─ 3054 133951 133952
─ SC ─ ─ 5054 133957 133958
─ SC ─ ─ 7554 133961 133962
─ SC ─ ─ 10054 138721 138730
Example
Model No.
Rotor Kit
Part No.
Stator /
Motor Housing
Kit Part No.
4SCMS75N4 138729 138738
Rotor Kit includes:
• Lower Shaft Snap Ring
• Upper Shaft Snap Ring
• Rotor
Stator/Motor Housing Kit includes:
• Motor Housing (painted)
• Pipe Plug
• Set Cap Screw
• Stator
• Self-clinching Tie Cable
• Cap Plug
1750 RPM
Model No. Motor Kit Part No.
─ SH ─ ─ 30N4 145663
─ SH ─ ─ 50N4 145666
─ SH ─ ─ 75N4 145668
─ SH ─ ─ 100N4 145670
Motor Kit includes:
• Lower Shaft Snap Ring
• Upper Shaft Snap Ring
• Rotor
• Motor Housing (Painted)
• Pipe Plug
• Set Cap Screw
• Stator
• Self-Clinching Tie Cable
• Cap Plug
• Terminal Block Kit
• Moisture Sensor Kit
• Bearing Bracket Kit
• Bearing Kit
* Motor kits ship pre-assembled
