Crane Barnes SITHE 3XSCM - Page 24

24
Slicer Blade Kit includes:
• Impeller (Balanced, trimmed)
• Blade (Pressed)
• Attachment Pins (Pressed)
(Components are Fully Assembled)
Slicer Blade Attachment Kit includes:
• Impeller Washer
• Impeller Bolt
• Impeller Key
“PA” Impeller
Trim Dia.
mm (in)
Ductile Iron
Slicer Blade Kit
Nihard
Slicer Blade Kit
Kit Component Info (Ref. ONLY)
Ductile Iron
Part No.
Nihard
Part No.
Blade Pin
205mm (8.07in) 137223-ASSY-KIT 143288-ASSY-KIT 137223-C 143288-C 142126 142133-0750
200mm (7.87in) 137223TA-ASSY-KIT 143288TA-ASSY-KIT 137223TA-C 143288TA-C 142126 142133-0750
195mm (7.68in) 137223TB-ASSY-KIT 143288TB-ASSY-KIT 137223TB-C 143288TB-C 142126 142133-0750
190mm (7.48in) 137223TC-ASSY-KIT 143288TC-ASSY-KIT 137223TC-C 143288TC-C 142126 142133-0750
185mm (7.28in) 137223TD-ASSY-KIT 143288TD-ASSY-KIT 137223TD-C 143288TD-C 142126 142133-0750
180mm (7.09in) 137223TE-ASSY-KIT 143288TE-ASSY-KIT 137223TE-C 143288TE-C 142126 142133-0750
175mm (6.89in) 137223TF-ASSY-KIT 143288TF-ASSY-KIT 137223TF-C 143288TF-C 142126 142133-0750
170mm (6.69in) 133044TG-ASSY-KIT 143288TG-ASSY-KIT 137223TG-C 143288TG-C 142126 142133-0750
“S” Impeller
Trim Dia.
mm (in)
Ductile Iron
Slicer Blade Kit
Nihard
Slicer Blade Kit
Kit Component Info (Ref. ONLY)
Ductile Iron
Part No.
Nihard
Part No.
Blade Pin
200mm (7.87in) 133044-ASSY-KIT 143287-ASSY-KIT 133044-C 143287-C 142136 142133-1000
195mm (7.68in) 133044TA-ASSY-KIT 143287TA-ASSY-KIT 133044TA-C 143287TA-C 142136 142133-1000
190mm (7.48in) 133044TB-ASSY-KIT 143287TB-ASSY-KIT 133044TB-C 143287TB-C 142136 142133-1000
185mm (7.28in) 133044TC-ASSY-KIT 143287TC-ASSY-KIT 133044TC-C 143287TC-C 142136 142133-1000
180mm (7.09in) 133044TD-ASSY-KIT 143287TD-ASSY-KIT 133044TD-C 143287TD-C 142136 142133-1000
175mm (6.89in) 133044TE-ASSY-KIT 143287TE-ASSY-KIT 133044TE-C 143287TE-C 142136 142133-1000
170mm (6.69in) 133044TF-ASSY-KIT 143287TF-ASSY-KIT 133044TF-C 143287TF-C 142136 142133-1000
165mm (6.50in) 133044TG-ASSY-KIT 143287TG-ASSY-KIT 133044TG-C 143287TG-C 142136 142133-1000
160mm (6.30in) 133044TH-ASSY-KIT 143287TH-ASSY-KIT 133044TH-C 143287TH-C 142136 142133-1000
155mm (6.10in) 133044TJ-ASSY-KIT 143287TJ-ASSY-KIT 133044TJ-C 143287TJ-C 142136 142133-1000
