25
Volute Kit includes:
• Wear Ring (pressed)
• Volute (painted)
Hardware Kit includes:
• Impeller key
• Volute attachment screws
• Impeller attachment screws
O-Ring Kit includes:
• Volute O-Ring (option 1)
• Volute O-Ring (option 2)
• Volute O-Ring (option 3)
• External Retaining Ring
NOTE: Kit contains hardware your pump may not require.
Cord Attachment Kit includes:
• Attachment screws
Lifting Handle Kit includes:
• Lifting Handle
• Attachment hardware
Additional Components
Component Part No. Single Sale Kit
Impeller See Table Yes N/A
Wear Ring See Table Yes Volute Kit, Shell Kit
Lifting Handle 133032 Yes N/A
Nameplate No Resale
Nameplate/Model Plate Rivets 001628 No Resale Rivet Kit (p/n 139398)
Seal Kits
Seal Kit
Part No.
Seal
Part No.
Seal
Material
138580-XP-CC 133029 Carbon / Ceramic
138580-XP-SD
(STD)
133029SD Silicon Carbide /
Silicon Carbide
138580-XP-TC 133029SB Tungsten Carbide /
Tungsten Carbide
Seal Kit includes:
• Volute O-Ring (option 1)
• Volute O-Ring (option 2)
• Volute O-Ring (option 3)
• Volute O-Ring (option 4)
• External Retaining Ring
• Lower Mechanical Seal
NOTE: Kit contains hardware your pump may not require.
Leg Kit includes:
• 3 Legs (painted)
• attachement hardware
Leg Kits
Model
Leg Kit
Part No.
Leg Kit Height
Inches (mm)
3XSCMPA 125506 3.15 (80)
4XSCMS 125506 3.15 (80)
4XSCDF 125506 3.15 (80)
4XSCMC 125506 3.15 (80)
4XSCDG 125506 3.15 (80)
4XSCMD 125506B 6.50 (165)
6XSCDO 125506B 6.50 (165)
4XSCMB 125506B 6.50 (165)
4XSCME 125506B 6.50 (165)
4XSCMEA 125506B 6.50 (165)
4XSCDI 125506B 6.50 (165)
6XSCMN 125506B 6.50 (165)
6XSCMH 125506B 6.50 (165)
6XSCMJ 125506B 6.50 (165)
6XSCDK 125506B 6.50 (165)
