Stringer Trailer Owner’s/Parts Manual
17
PN:90806-00 R090114
OPERATION
5.8 ADJUSTING THE PUMP
To adjust the fl ow in the hydraulic pump to more pressure
turn screw 1/4 turn at a time clockwise and test. Do this until
desired pressure has been obtained
To adjust pressure to less pressure turn 1/4 turn counter
clockwise. Do this until desired pressure has been obtained.
Figure 8: Adjusting the pump
5.9 FILLING THE PUMP
Fill with Dexron transmission fl uid. It’s best to leave about
an inch of space from the bottom of the neck of the port to
allow for any overfi ll seepage.
Figure 9: Hydraulic Pump refi ll port.
5.10 SECURE THE JACK
Make sure that the pin is completely inserted through the
mounting holes, and is seen extending through the bottom
hole.
Figure 10: Secure the jack
