Tile Plow Owner’s/Parts Manual
36
PN:90806-00 R090114
SERIAL NUMBER LOCATION
Always give Lockwood the serial number of your machine when ordering parts, requesting
service, or any other information.
Please record the serial number in the space provided on the front cover and on the war-
ranty and registration card.
OPERATOR ORIENTATION
All references to left, right, front and rear of the machine, as mentioned throughout the manual, are determined by standing behind
the machine and facing the direction of forward travel. The arrow on each illustration page indicates the direction of forward travel.
ILLUSTRATIONS AND PARTS LISTS
The arrangement of this parts catalog is for easy identification of parts. All parts are illustrated in either assembled or exploded views.
All illustrations are located on the left hand page with the associated parts list on the right. Except for some common hardware, all
parts are identified with an item number which corresponds to the item column on the parts list page. The parts list pages list the item
number, part number, part description and the quantity required.
PAGE HEADERS AND DESCRIPTIONS
1- Illustration description. 5- Part number.
2- Models. 6- Part description.
3- Revision date of page.
7- Total quantity of the part referred to on the page. Can be
replaced by AR = quantity as required.
4- Item number of part (on illustration).
BASE (0884-0647-00)
ITEM PART NUMBER DESCRIPTION QTY
1 0018-0734-17 WELDMENT, MAIN FAME 1
2 0025-1491-17 MOUNT, STANDING PLATFORM 2
09/14 BASE
3 2 1
4 5
6
7
BASE 09/14
1 2 3
ARROW INDICATES DIRECTION OF FORWARD TRAVEL
ILLUSTRATION PAGE HEADER:
PARTS LIST PAGE HEADER:
