Tile Plow Owner’s/Parts Manual
41
PN:90806-00 R090114
09/14 3PT STRINGER
ASSEMBLY, STRINGER 3 PT ( 90238)
ITEM PART NUMBER DESCRIPTION QTY
1 0122-0169-00 HAIRPIN, .178 X 3.562 Z PL 2
2 0537-0003-00 ZERK, STR .62LG DRIVE .18 HOLE 1
3 15006 BOLT, 3/8 X 1 HEX GR5 ZP 5
4 15042 NUT, 3/8 HEX NC ZP 2
5 15139 WASHER, 3/8 LOCK ZP 5
6 15191 BOLT, 1/2 X 3/4 HEX GR5 NC ZP 2
7 15935-00 PIN, SNAP, 5/16 X 2-1/4" USABLE LENGTH 1
8 32553-12 CYLINDER, 3.5 X 16 X 1.38 0DEG HYDRAULIC 1
9 32562-00 CLAMP, DOUBLE TUBE, .687 DIA, VINYL COATED 3
10 32804-00 BRAKES, DRUM, 12" X 2" 1
11 32880-00 ASSEMBLY, SPINDLE - TABLE 1
12 32889-00 DECAL, CTP, WEB 2
13 32898-00 DECAL, TILE PRO, LARGE 1
14 32901-00 DECAL, 8II CALL BEFORE YOU DIG, HORIZONTAL 2
15 90369-33 WELDMENT, TABLE STOP 1
16 90388-33 WELDMENT, BRAKE DRUM/HUB 1
17 90399-00 ASSEMBLY, STRINGER TABLE (PAGE 51) 1
18 90427-00 ASSEMBLY, OCTAGON SPOOL TOP (PAGE 52) 1
19 90435-00 ASSEMBLY, MAST TUBE (PAGE 53) 1
20 90568-33 WELDMENT, MAIN, STRINGER, 3-POINT 1
21 90805-00 ASSEMBLY, SWITCH - SPOOL BRAKE 1
22 90826-33 MOUNT, UPPER STRINGER 3-POINT ROUND 1
23 90845-00 WIRE, BRAKES, STRINGER, 3-POINT 1
24 90846-00 KIT, HOSE, STRINGER, 3-POINT 1
16605 COUPLER, 1/2 X -8FORING MALE 2
90847-00 HOSE,.375X132 -8MORING/-8MORING90SW 1
90848-00 HOSE,.375X150 -8MORING/-8MORING90SW 1
90802-00 TUBING, HEAT SHRINK - 3/8" 3:1 RATIO (NOT SHOWN) 2
15928-00 WIRE NUT, BLUE (NOT SHOWN) 2
