Crary PRO - Page 53

Tile Plow Owner’s/Parts Manual
47
PN:90806-00 R090114
09/14 STRINGER TRAILER - BASE
ASSEMBLY, DUAL AXLE STRINGER TRAILER BASE ( 90347-00)
ITEM PART NUMBER DESCRIPTION QTY
1 0122-0230-00 PIN, HAIRPIN .120 X 2.375 Z PL 2
2 0537-0003-00 ZERK, STR .62LG DRIVE .18 HOLE 5
3 15006 BOLT, 3/8 X 1 HEX GR5 ZP 2
4 15042 NUT
, 3/8 HEX NC ZP
2
5 15139 WASHER, 3/8 LOCK ZP 2
6 15191 BOLT, 1/2 X 3/4 HEX GR5 NC ZP 2
7 15935-00 PIN, SNAP, 5/16 X 2-1/4" USABLE LENGTH 1
8 32553-12 CYLINDER, 3.5 X 16 X 1.38 0DEG HYDRAULIC 1
9 32790-00 JACK, 1-TON SQUARE 1
10 32804-00 BRAKES, DRUM, 12" X 2" 1
11 32880-00 ASSEMBLY, SPINDLE - TABLE 1
12 32889-00 DECAL, CTP, WEB 2
13 32898-00 DECAL, TILE PRO, LARGE 1
14 32901-00 DECAL, 8II CALL BEFORE YOU DIG, HORIZONTAL 1
15 90246-00 ASSEMBLY, WHEEL 11L15 4
16 90299-33 WELDMENT, STRINGER TRAILER, MAIN 1
17 90369-33 WELDMENT, TABLE STOP 1
18 90372-33 WELDMENT, REAR HITCH TONGUE 1
19 90376-33 WELDMENT, CLEVIS PIN 1
20 90380-33 WELDMENT, REAR HITCH PIN 1
21 90388-33 WELD, BRAKE DRUM/HUB 1
22 90399-00 ASSEMBLY, STRINGER TABLE (PAGE 51) 1
23 90427-00 ASSEMBLY, OCTAGON SPOOL TOP (PAGE 52) 1
24 90435-00 ASSEMBLY, MAST TUBE (PAGE 53) 1
25 90552-33 ASSEMBLY, TANDEM AXLE 2
