Creality Ender-5 User Manual

1. Prepare →Auto Home. Wait for the nozzle to move to the
left/front of the platform.
2. Prepare→Disable Steppers(Close stepper drive，release
motor)
3. Move the nozzle the front/left leveling screw and adjust the platform
height by turning the knob underneath. Use a piece of A4 paper (standard
printer paper) to assist with the adjustment, making sure that the nozzle
lightly scratches the paper.
4. Complete the adjustment of the screw on all 4 corners.
5. Repeat above steps 1-2 times if necessary.
1 2
34
7. Bed Leveling
12

Creality Ender-5 Specifications

General

Build Volume	220 x 220 x 300 mm
Filament Diameter	1.75 mm
Bed Leveling	Manual
Heated Bed	Yes
Max Nozzle Temperature	260°C
Print Technology	FDM (Fused Deposition Modeling)
Display	LCD
Layer Resolution	0.1 - 0.4 mm
Nozzle Diameter	0.4 mm
Supported Filaments	PLA, ABS, TPU, PETG
Connectivity	SD Card, USB
Frame Material	Aluminum
