在线工作
Online operation
开始
Start
断开电源
Disconnect the power
拔出X\Y电机线及限位开关线
Pull out the X\Y motor
wire and limit switch wire
连接控制盒和打印机
Connect the control
box to the printer
安装激光模组固定板
Install the laser
module fixing plate
安装激光模组
Install the laser module
插入激光模组线
Plug Laser Module wire
放置金属保护板及雕刻材料
Placing metal protective plates
and engraving materials
调整激光模组焦距
Adjust focus of laser module
接通电源并打开开关
Connect power and
turn on the switch
在软件中选择对应COM口,
连接控制盒
Select the corresponding
COM port in the software
and connect the control box
修改GRBL配置参数并
重启控制盒
Modify the GRBL
configuration parameters
and restart the control box
在软件中导入图片
Import pictures into
the software
设置参数
Setting parameters
边框预览
Frame preview
开始雕刻
Start engraving
使用Type-C数据线连接电脑和
控制盒 Use a Type-C data
cable to connect the
computer and the control box
结束
End
