KNX Control Interface Crestron CI-KNX
8
KNX Control Interface: Crestron CI-KNX Operations & Installation Guide – DOC. 0008
whether the communication partner is the local network. If the partner
is not in the local network, then the device sends the IP telegrams not
directly to the partner but to the gateway, which forwards the telegrams
to the device.
IP-Gateway-Address:
Enter the IP-Address of the gateway here.
Hint: Fill out 0.0.0.0 if the Crestron CI-KNX is only used in the local
LAN.
Example for IP-Address assignment
The Crestron CI-KNX shall be accessed using a PC
IP-Address of the PC: 192.168.1.30
Subnet of the PC: 255.255.25.0
The Crestron CI-KNX is located in the same local LAN therefore it
uses the same subnet mask. Because of the used subnet mask the IP-
address assignment is limited, only addresses with format 192.168.xx
can be assigned to the device, xx stands for the range 1-255 (without
30, because this host number is already assigned to the PC). Be careful
not to use one IP-address more than once.
IP-address of the Crestron CI-KNX: 192.168.1.31
Sub network of the Crestron CI-KNX: 255.255.255.0
Data points:
Up to 250 data points can be parameterized. Each data point gets a group
address, in order to send to the bus. More than one group address can be set for
one object.
