Crestron DigitalMedia Room Controller DM-RMC-100 - Connectors, Controls & Indicators

Crestron DM-RMC-100 DigitalMedia™ Room Controller, CAT
DM-RMC-100 Overall Dimensions (Rear View)
Connectors, Controls & Indicators
# CONNECTORS
1
,
CONTROLS &
INDICATORS
DESCRIPTION
1 PWR LED (1) Green LED, indicates
operating power supplied via
DMNet
2 DM LINK LED (1) Green LED, indicates
connection to an upstream DM
device
(Continued on following page)
Operations & Installation Guide – DOC. 6743-1F Room Controller, CAT: DM-RMC-100 • 13
