15 Inch Tilt Touchpanel Crestron Isys™ TPS-6000
XGA Analog Reserved Join Numbers for TPS-6000 Touchpanels
*
JOIN # FUNCTION VALUE IN/OUT
17000 Gain R
Gain for Red INPUT
17001 Gain G Gain for Green INPUT
17002 Gain B
Gain for Blue
INPUT
17003 Matches Preset Number Matched Preset OUTPUT
17004 Frequency: Vertical Vertical Frequency OUTPUT
17005 Frequency: Horizontal Horizontal Frequency OUTPUT
17006 Size: Vertical Vertical Size (Pixels) OUTPUT
17007 Size: Horizontal Horizontal Size (Pixels) OUTPUT
17008 Selected Preset Selected Preset OUTPUT
* These join numbers are available only when the TPS-XVGA is installed.
XGA Digital Reserved Join Numbers for TPS-6000 Touchpanels
1
JOIN # FUNCTION VALUE IN/OUT
17001 Move Right INPUT
17002 Move Left INPUT
17003 Move Up INPUT
17004 Move Down INPUT
17005 Stretch Stretch INPUT
17006 Shrink Shrink INPUT
17007 Stretch Stretch INPUT
17008 Shrink Shrink INPUT
17009 Phase Shift Forward INPUT
17010 Phase Shift Reverse INPUT
17011 XGA Auto Detect
On INPUT/OUTPUT
17012 XGA Auto Detect Off INPUT/OUTPUT
17013 XGA Recenter Recenter INPUT
17014 Save Preset Save Preset INPUT
17015 Erase Preset Erase Preset INPUT
17016
through
17031
XGA Preset
XGA Preference
Setting
2
INPUT/OUTPUT
17032 No Input Flag No XGA input OUTPUT
17033 Empty Preset
Current preset has
no stored settings
OUTPUT
17034 Gain R Increase INPUT
17035 Gain R Decrease INPUT
17036 Gain G Increase INPUT
17037 Gain G Decrease INPUT
17038 Gain B Increase INPUT
17039 Gain B Decrease INPUT
17040 Defaults
3
Defaults INPUT
17041 Default Colors
4
Default Colors INPUT
1. These join numbers are available only when the TPS-XVGA is installed.
36 • 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 Operations Guide - DOC. 5864A
