Crestron Isys™ TPS-6000 15 Inch Tilt Touchpanel
15 Inch Tilt Touchpanel:
Crestron Isys™ TPS-6000
Introduction
Features and Functions
The TPS-6000 packs all the power and performance of an Isys panel in a stylish tilt
model. These units are suitable for tabletop mounting in any Crestron
®
control
system (herein referred to as the Cresnet
®
system) and are perfect for the conference
room or home theater.
Featuring a 15-inch (38.1 cm) active matrix display, the TPS-6000 uses the 65,536-
color Isys engine that allows all graphics to be displayed with incredible brightness
and depth.
TPS-6000 Functional Summary
• 15" (38.1 cm) diagonal active matrix color display
• 1024 x 768 (XGA) Native Screen Resolution
• 16 Bit non-palette graphics, over 64,000 colors
• 8 Mb of Flash, expandable to 16 or 32 Mb with Crestron
®
plug-in
memory modules to accommodate larger touchpanel projects & 8 Mb o
f
DRAM memory
• Unique modular system allows configuration of capabilities simply by
adding expansion cards for video, computer graphics, and Internet
• Displays RGB video at native resolution with optional
TPS-XVGA interface card
• Displays one NTSC/PAL/S-video/composite video source with 256,000
colors with optional TPS-VID-1 expansion card
• Displays two NTSC/PAL/composite video (or one S-video) sources
with 256,000 colors with optional TPS-VID-2 expansion card
• 10/100 BaseT (full/half duplex) Ethernet capabilities with optional
TPS-ENET expansion card. Supports dynamic and static IP addressing
• Up to 4,000 digital and analog signal joins; up to 999 serial signal joins
• Built-in microphone, mixer, amplifier, stereo speakers, and line-level
input/output
• Stores and plays WAV files
(continued on next page)
Operations Guide - DOC. 5864A 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 • 1
