15 Inch Tilt Touchpanel Crestron Isys™ TPS-6000
TPS-6000 Functional Summary (continued)
• Local RS-232 port for console control; adds ability to upload firmware
or touchpanel projects
• Wireless operation with optional TPS-XTXRF
• Pop-up sub pages to reduce memory requirements, providing optimal
speed and performance
• Multiple button, slider control, and icon configurations, including
multi-mode objects
• Fast graphics performance: imported photographs, drawings, and icons
• Support for downloadable fonts – proportional and non-proportional
• Foreign language text
• Position lock feature provides durable support of panel at any angle of
inclination between 30 and 80 degrees
Multiple graphics can be displayed on the TPS-6000 without any shift in color depth
or quality. The touchpanel can support real-time video with the optional
TPS-VID-1 or TPS-VID-2 cards, RGB computer graphics with the optional
TPS-XVGA RGB Interface card, and 10/100 BaseT TCP/IP network
communications with the optional TPS-ENET Ethernet module.
The TPS-6000’s audio capabilities include stereo audio speakers that offer volume
control, a built-in microphone with line-level output, built-in WAV sound file
capability and line-level input for other audio sources.
The purpose of the TPS-6000 touchpanel is to replace large, complicated hard-wired
panels in either a Cresnet system or an RS-232 system with a series of simpler
screens each specific to the control problem at hand. Thus, a very large number of
functions can be made available to the user without the confusion associated with
hardware panels of that complexity. Icons, graphics, and text can dramatically
increase any user's comprehension of the control environment. Devices, functions,
and control zones are quickly organized and more easily accessed.
The TPS-6000 has the ability to transmit touch coordinates when "RS-232 Port for
Touch Output" is selected. Currently Telestrator devices are supported on the
TPS-6000. Refer to the "RS-232 Menu" section of "Configuring the Touchpanel" on
page 14 and “Appendix B: Configuring the RS-232 Port for Use” on page 49 for
instructions on selecting this feature.
2 • 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 Operations Guide - DOC. 5864A
